ASUS TUF GAMING B660M-PLUS D4 (LGA 1700) mATX motherboard, 10+1 DrMOS Power stages , PCIe 5.0 support, DDR4 5333 (OC), Dual PCIe 4.0 M.2 Slots with Flexible Heatsink, Realtek 2.5Gb Ethernet, Rear USB 3.2 Gen 2×2 Type-C®, Front USB 3.2 Gen 1 Type-C®, Aura Sync, Two-way AI Noise Cancelation

Name: ASUS TUF GAMING B660M-PLUS D4 (LGA 1700) mATX motherboard, 10+1 DrMOS Power stages , PCIe 5.0 support, DDR4 5333 (OC), Dual PCIe 4.0 M.2 Slots with Flexible Heatsink, Realtek 2.5Gb Ethernet, Rear USB 3.2 Gen 2x2 Type-C®, Front USB 3.2 Gen 1 Type-C®, Aura Sync, Two-way AI Noise Cancelation
Brand: Asus
SKU: MC-MBD-ASU-0118
Price: 58000 PKR
Availability: InStock

SKU: MC-MBD-ASU-0118 Category: Intel Motherboards Brand: Asus

The ASUS TUF GAMING B660M-PLUS D4 is a micro ATX motherboard for 12th Gen Intel CPUs, featuring a 10+1 DrMOS power design, PCIe 5.0 support, and DDR4 memory up to 5333 MHz (OC). It includes dual PCIe 4.0 M.2 slots with a flexible heatsink, Realtek 2.5Gb Ethernet, and comprehensive USB connectivity with Type-C ports. Built for durability and performance, it’s ideal for reliable gaming and productivity builds.

Shipping & Delivery

Pick up from the Megacomputer Store

To pick up today

Free

Express delivery

Applicable to selected areas in Karachi only

1-2 Days

TCS Courier delivery

Our courier partner will deliver to your specified address

Delays may occur due to situations out of our control

3-4 Days

₨ 58,000

Compare

Add to wishlist

Description

The ASUS TUF GAMING B660M-PLUS D4 is a micro ATX motherboard built for 12th Gen Intel Core processors on the LGA 1700 socket. It features a robust 10+1 DrMOS power stage design, ensuring stable power delivery for demanding workloads and gaming. With PCIe 5.0 support on the primary x16 slot, you’re ready for next-gen graphics cards.

Memory flexibility is key, supporting DDR4 up to 5333 MHz (OC) across four slots, with a maximum capacity of 128GB. Dual PCIe 4.0 M.2 slots come with a flexible heatsink to keep your SSDs cool, while Realtek 2.5Gb Ethernet provides fast, reliable networking. The rear I/O includes USB 3.2 Gen 2×2 Type-C and multiple USB 3.2 Gen 2 ports, plus front USB 3.2 Gen 1 Type-C support.

10+1 DrMOS power stages for efficient and stable power delivery
PCIe 5.0 x16 slot for next-gen graphics cards
DDR4 memory support up to 5333 MHz (OC) with 128GB max
Dual PCIe 4.0 M.2 slots with flexible heatsink
Realtek 2.5Gb Ethernet for high-speed wired networking
Rear USB 3.2 Gen 2×2 Type-C and front USB 3.2 Gen 1 Type-C

Specification

Overview

Brand	ASUS
Model	TUF GAMING B660M-PLUS D4
CPU Socket Type	LGA 1700
CPU Type	Supports 12th Gen Intel Core / Pentium Gold / Celeron Processors, * Refer to www.asus.com for CPU support list.
Supported CPU Technologies	Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset	Intel B660
Onboard Video Chipset	Supported only by CPU with integrated graphic
Number of Memory Slots	4x288pin (DDR4)
Memory Standard	DDR4 5333(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133, Actual Memory frequency support depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Maximum Memory Supported	128GB
Channel Supported	Dual Channel
PCI Express 5.0 x16	1 x PCI Express 5.0 x16, * Actual support may vary by CPU.
PCI Express 3.0 x16	1 x PCI Express 3.0 x16, * Supports x4 mode.
PCI Express x1	1 x PCIe 4.0 x1
SATA 6Gb/s	4 x SATA 6Gb/s
M.2	Intel 12th Gen Processors:, M.2_1 slot (Key M), type 2242/2260/2280, – Intel 12th Gen processors support PCIe 4.0 x4 mode., Intel B660 Chipset:, M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots.
Intel Optane Ready	Yes
SATA RAID	0/1/5/10
Audio Chipset	Realtek 7.1 Surround Sound High Definition Audio CODEC
Audio Channels	7.1 Channels
LAN Chipset	Realtek 2.5Gb Ethernet
Max LAN Speed	10/100/1000/2500Mbps
Back I/O Ports	1 x USB 3.2 Gen 2×2 port (1 x USB Type-C), 4 x USB 3.2 Gen 2 ports (4 x Type-A), 1 x USB 3.2 Gen 1 port (1 x Type-A), 2 x USB 2.0 ports (2 x Type-A), 1 x DisplayPort, 1 x HDMI port, 1 x Realtek 2.5Gb Ethernet port, 5 x Audio jacks, 1 x Optical S/PDIF out port
Onboard USB	1 x USB 3.2 Gen 1 connector (supports USB Type-C), 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports, 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Other Connectors	Fan and Cooling related, 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 3 x 4-pin Chassis Fan headers, Miscellaneous, 3 x Addressable Gen 2 headers, 1 x AURA RGB header, 1 x Clear CMOS header, 1 x COM Port header, 1 x Front Panel Audio header (AAFP), 1 x 20-3 pin System Panel header with Chassis intrude function, 1 x Thunderbolt header
Form Factor	Micro ATX
LED Lighting	RGB
Dimensions (W x L)	9.6″ x 9.6″
Power Pin	1 x 24-pin Main Power connector, 1 x 8-pin +12V Power connector, 1 x 4-pin +12V Power connector
Windows 11	Ready
Package Contents	Accessories:, Cables, 2 x SATA 6Gb/s cables, Miscellaneous, 1 x M.2 Rubber package, 1 x M.2 SSD screw package, 1 x TUF Gaming sticker, Application DVD, 1 x Support DVD, Documentation, 1 x TUF Certification card, 1 x User Guid
Form Factor	Micro-ATX
Memory Type	DDR4
