Asus Prime H610M-K D4 Intel® H610 (LGA 1700) mic-ATX motherboard with DDR4, PCIe 4.0, M.2 slot, Realtek 1 Gb Ethernet, HDMI®, D-Sub, USB 3.2 Gen 1 ports, SATA 6 Gbps, COM header, RGB header
- Intel® LGA 1700 socket: Ready for 13th & 12th Gen Intel® processors
- Comprehensive cooling: PCH heatsink and Fan Xpert
- Ultrafast connectivity: 32Gbps M.2 slot, Realtek 1 Gb Ethernet and USB 3.2 Gen 1 support
- 5X Protection III: Multiple hardware safeguards for all-round protection
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 24,999
Description
Asus Prime H610M-K D4 Intel® H610 (LGA 1700) mic-ATX motherboard with DDR4, PCIe 4.0, M.2 slot, Realtek 1 Gb Ethernet, HDMI®, D-Sub, USB 3.2 Gen 1 ports, SATA 6 Gbps, COM header, RGB header Price in Pakistan Specs
CPU
Rear Panel I/O Ports
Internal I/O Connectors
Memory
Motherboard
Expansion
Graphics Device
Sound
Warranty
Network
System Requirements
System
Physical
Key Features
Wide Range of Motherboard / Chipset Asus, MSI, Gigabyte, Palit GameRock, Palit GamingPro , PNY, Asus ROG, Asus Tuf, Asus Cerberus, Colorful, XFX, Zotac, Sapphire, Motherboard and Chipset Price in Pakistan, Best Deals Price in Pakistan, ALL GPU and Graphics Cards Best Lowest Price, Rates in Pakistan, Karachi, Lahore, Islamabad, Multan, Peshawar. ASUS ROG STRIX B550-XE GAMING (WIFI) AMD B550 Ryzen AM4 ATX Gaming Motherboard ASUS ROG STRIX B460-H GAMING LGA 1200 ATX Motherboard
Specification
Overview
| Warranty | 3 Years |
|---|---|
| CPU Socket | Socket 1700 |
| CPU Brand | Intel |
| Installed Processors (Max) | 0 (1) |
| Supported Processor Manufacturer | Intel |
| Supported Processors | 12th Gen Intel Core, Pentium Gold and Celeron Processors |
| 64-bit Support | Yes |
| Socket | LGA1700 |
| USB Ports | 2 x USB 3.0, 4 x USB 2.0 |
| HDMI Port | 1 x HDMI 2.1 |
| VGA Port | 1 x D-Sub |
| Keyboard/Mouse Combo Port | 1 x PS/2 |
| RJ-45 Ports | 1 x RJ-45 |
| Audio Line In Ports | 1 x 3.5mm Jack |
| Audio Line Out Ports | 1 x 3.5mm Jack |
| Microphone In Port | 1 x 3.5mm Jack |
| SATA Connectors | 4 x SATA III |
| USB Connectors | 1 x USB 3.0 header (supports 2 ports), 1 x USB 2.0 header (supports 2 ports) |
| Speaker | 1 x Speaker header |
| Front Panel Connectors | 1 x Front Panel, 1 x Front Audio |
| Cooling Fan Support | 1 x CPU fan header, 1 x Chassis fan header |
| S/PDIF Connectors | 1 x S/PDIF Out header |
| Serial Connectors | 1 x COM header |
| TPM Header | 1 x SPI TPM header |
| Power Connector Port | 1 x 24-pin ATX, 1 x 8-pin EPS |
| Other Connectors | 1 x M.2 slot, Key M, Type 2242/2260/2280 (PCIe Gen3 or SATA), 1 x 4-pin RGB LED header |
| Memory Bus Speed | Up to 3200 MHz |
| Memory Type | DDR4 |
| Maximum RAM | 64 GB |
| Memory Slot | 2 x DIMM |
| Chipset Manufacturer | Intel |
| Northbridge | H610 |
| RAID Supported | No |
| SATA Supported | Yes |
| Number of PCI Express Slots | 1 x PCI Express 4.0 x16 slot, 1 x PCI Express 3.0 x1 slot |
| Integrated Graphics Supported | Yes |
| Integrated Sound | Realtek |
| Integrated Network | Realtek |
| Network Speeds Supported | Up to 1 Gbps |
| Wireless LAN | No |
| Bluetooth | No |
| Operating Systems Supported | Microsoft Windows 11 / 10 64-bit |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Software Included (may be trial or restricted) | Yes |
| Drivers | Yes |
| Form Factor | MicroATX Motherboard |
| In The Box | ASUS Prime H610M-K D4 Motherboard, 2 x SATA 6Gb/s cables, 1 x I/O Shield, 1 x M.2 ANCHOR, 1 x Support DVD, 1 x User Guide |
| Width | 234 mm |
| Length | 203 mm |
| Firewire | No |
| Wireless Network | No |
| Memory Channel | Dual |
| On-board Audio Type | 7.1 |
| Number of SATA Ports | 4 port(s) |
| Number of USB Ports | 6 port(s) |
| SATA III Support | Yes |
| USB 3.0 Support | Yes |
| Multi GPU Support | No |
| VGA Connection | Yes |
| DVI Connection | No |
| HDMI Connection | Yes |
| DisplayPort Connection | No |
| Motherboard Form Factor | mATX |
| Motherboard Power Connectors | 8-Pin |
| Motherboard Chipset | Intel H610 |
| Thunderbolt | No |
| Motherboard Model | ASUS Prime H610M-K D4 |
| USB 3.1 Support | No |
| Internal USB3.0 Header | Yes |
| M.2 Support | Yes |
| On-board RGB Control | ASUS Aura Sync |
| Memory Speed | 3200 MHz |
| RGB Header Type | 4-Pin RGB |
| Addressable RGB | No |
| Form Factor | ATX |
| Memory Type | DDR4 |
