MSI PRO Z790-S WiFi DDR5 Motherboard (Supports 12th/13th Gen Intel Processors, LGA 1700, DDR5, PCIe 5.0, M.2, 2.5Gbps LAN, USB 3.2 Gen2, Wi-Fi 6E, ATX)

Name: MSI PRO Z790-S WiFi DDR5 Motherboard (Supports 12th/13th Gen Intel Processors, LGA 1700, DDR5, PCIe 5.0, M.2, 2.5Gbps LAN, USB 3.2 Gen2, Wi-Fi 6E, ATX)
Brand: MSI
SKU: MC-MBD-MSI-0073
Price: 63500 PKR
Availability: InStock

SKU: MC-MBD-MSI-0073 Category: Intel Motherboards Brand: MSI

The MSI PRO Z790-S WiFi DDR5 Motherboard supports Intel 12th/13th Gen processors with LGA 1700 socket, featuring DDR5 memory up to 6600+ MHz, PCIe 5.0, dual M.2 slots, 2.5Gbps LAN, and Wi-Fi 6E. Its extended heatsink and Frozr AI Cooling ensure stable performance for demanding tasks. Available with nationwide delivery and cash-on-delivery across Pakistan.

Shipping & Delivery

Pick up from the Megacomputer Store

To pick up today

Free

Express delivery

Applicable to selected areas in Karachi only

1-2 Days

TCS Courier delivery

Our courier partner will deliver to your specified address

Delays may occur due to situations out of our control

3-4 Days

₨ 63,500

Compare

Add to wishlist

Description

The MSI PRO Z790-S WiFi DDR5 Motherboard is designed for Intel 12th/13th Gen processors with LGA 1700 socket, offering a robust platform for gaming and productivity. It supports DDR5 memory up to 6600+ MHz (OC) with a maximum capacity of 192GB, ensuring fast multitasking and application performance.

Equipped with PCIe 5.0 for next-gen graphics and storage, dual M.2 slots with Shield FROZR thermal solutions, and 2.5Gbps LAN plus Wi-Fi 6E for high-speed connectivity. The ATX form factor includes an extended heatsink design and Frozr AI Cooling for efficient thermal management.

Supports Intel 12th/13th Gen Core, Pentium Gold, and Celeron processors (LGA 1700)
4x DDR5 slots, dual channel, up to 192GB, with Intel XMP 3.0 support
PCIe 5.0 x16 slot for high-bandwidth graphics cards
2x M.2 slots (PCIe 4.0 x4) with M.2 Shield FROZR heatsinks
Realtek 2.5Gbps LAN and Intel Wi-Fi 6E with Bluetooth 5.3
Extended heatsink design and Frozr AI Cooling for stable performance

Specification

Overview

Warranty	2 Years
Best Seller Ranking	#20 in Intel Motherboards
Brand	MSI
Model	PRO Z790-S WIFI
CPU Socket Type	LGA 1700
CPU Type	Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors
Chipset	Intel Z790
Number of Memory Slots	4x288pin (DDR5)
Memory Standard	Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz, Max. overclocking frequency:, – 1DPC 1R Max speed up to 6600+ MHz, – 1DPC 2R Max speed up to 6400+ MHz, – 2DPC 1R Max speed up to 6000+ MHz, – 2DPC 2R Max speed up to 5600+ MHz
Maximum Memory Supported	192GB
Channel Supported	Dual Channel
Memory Feature	Supports Intel XMP 3.0 OC, Supports Dual-Controller Dual-Channel mode, Supports non-ECC, un-buffered memory
PCI Express 5.0 x16	PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI Express 3.0 x16	PCI_E3 Gen PCIe 3.0 supports up to x4 (From Chipset)
PCI Express x1	3x PCI-E x1 slot, PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset)
SATA 6Gb/s	4 x SATA 6Gb/s
M.2	2x M.2, M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices, M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
SATA RAID	0/1/5/10
Audio Chipset	Realtek ALC897 Codec, 7.1-Channel High Definition Audio, Supports S/PDIF output
Audio Channels	7.1 Channels
LAN Chipset	Realtek RTL8125BG 2.5Gbps LAN
Max LAN Speed	2.5Gbps
Wireless LAN	Intel Wi-Fi 6E, The Wireless module is pre-installed in the M.2_WIFI1 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax, * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
Bluetooth	Supports Bluetooth 5.3, FIPS, FISMA, * Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
Back I/O Ports	1 x DisplayPort / 1 x HDMI / 1 x LAN (RJ45) / 1 x Optical S/PDIF Out / 1 x USB 3.2 Gen 2×2 Type-C / 2 x USB 2.0/1.1 / 4 x USB 3.2 Gen 1 Type-A / 5 x Audio Jacks
Onboard USB	4x USB 2.0 ports, 4x USB 3.2 Gen1 Type A ports
Other Connectors	1x Power Connector (ATX_PWR), 2x Power Connector (CPU_PWR), 1x CPU Fan, 1x Pump Fan, 4x System Fan, 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD), 1x TBT connector (JTBT, supports RTD3), 1x RGB LED connector (JRGB), 1x TPM pin header (Support TPM 2.0)
Form Factor	ATX
Dimensions (W x L)	12.0″ x 9.6″
Windows 11	Supported
Features	Lightning Gen 5, The latest PCIe 5.0 solution with up to 128GB/s bandwidth for, maximum transfer speed., Wi-Fi 6E, The latest wireless solution supports 6GHz spectrum, MU-MIMO, and BSS color technology, delivering speeds up to 2400Mbps., Lightning USB 20G, Built-in USB 3.2 Gen 2×2 port, offers 20Gbps transmission speed,, 4X faster than USB 3.2 Gen 1., Extended Heatsink Design, MSI extended PWM heatsink and enhanced circuit design ensures, even high-end processors to run in full speed., M.2 Shield FROZR, Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe, while preventing throttling, making them run faster., 2.5G Network Solution, Featuring premium 2.5G LAN to deliver better network, experience., Frozr AI Cooling, Detect CPU & GPU temperatures and automatically adjust system, fan duty to a proper value., Memory Boost, Advanced technology to deliver pure data signals for the best, performance, stability and compatibility., Core Boost, With premium layout and fully digital power design to support, more cores and provide better performance.
Form Factor	ATX
Memory Type	DDR5
