Gigabyte X870E Aorus Master AMD AM5 LGA 1718 Motherboard, ATX, DDR5, 4X M.2, PCIe 5.0, USB4, WIFI7, 5GbE LAN, EZ-Latch
The Gigabyte X870E Aorus Master is an AMD AM5 ATX motherboard with the X870E chipset, supporting Ryzen 7000/8000/9000 series CPUs. It features DDR5 memory up to 256GB, PCIe 5.0, four M.2 slots, USB4, Wi-Fi 7, and 5GbE LAN, delivering top-tier performance for gaming and professional workloads. Available with nationwide delivery and cash-on-delivery in Pakistan.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 167,500
Description
The Gigabyte X870E Aorus Master is a premium ATX motherboard built for AMD AM5 LGA 1718 socket, supporting Ryzen 7000, 8000, and 9000 series processors. With the AMD X870E chipset, it offers cutting-edge connectivity including PCIe 5.0, USB4, and Wi-Fi 7, making it an ideal choice for high-performance gaming and content creation.
This motherboard features 4 DDR5 memory slots supporting up to 256GB, with overclocking capabilities up to DDR5 8200 MT/s. Storage is handled by 4 M.2 slots (3 PCIe 5.0 and 1 PCIe 4.0) and 4 SATA 6Gb/s ports, with RAID 0/1/5/10 support. Networking includes 5GbE LAN and Wi-Fi 7 with Bluetooth 5.3, while the Realtek ALC1220 audio codec delivers 7.1-channel sound.
- AMD AM5 socket with X870E chipset, supports Ryzen 9000/8000/7000 series
- 4x DDR5 slots, up to 256GB, overclocking to 8200 MT/s
- 4x M.2 slots (3 PCIe 5.0, 1 PCIe 4.0) and 4x SATA 6Gb/s with RAID
- PCIe 5.0 x16 slot, USB4 Type-C, Wi-Fi 7, 5GbE LAN
- EZ-Latch for easy M.2 and graphics card installation
- ATX form factor, 1-year warranty, nationwide delivery with cash-on-delivery available
Specification
Overview
| Brand | Gigabyte |
|---|---|
| Model | X870E Aorus Master |
| Socket | AM5 LGA 1718 |
| Form Factor | ATX |
| Memory Type | DDR5 |
| M.2 Slots | 4 |
| PCIe Version | 5.0 |
| USB4 | Yes |
| WiFi | WiFi 7 |
| LAN | 5GbE |
| Chipset | AMD X870E |
| Warranty | 1 Year |
| CPU Socket Type | AM5 |
| CPU Type | Ryzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series |
| Number of Memory Slots | 4x288pin |
| Memory Standard | DDR5 5200 |
| Maximum Memory Supported | 256GB |
| Channel Supported | Dual Channel |
| ECC Supported | Non-ECC |
| Buffer Supported | Un-buffered |
| Memory Feature | Support for DDR5 8200 / 8000 / 7800 / 7600 / 7200 / 7000 / 6800 / 6666 / 6600 / 6400 / 6200 / 6000 / 5600 / 5200 / 4800 / 4400 MT/s memory modules |
| PCI Express 5.0 x16 | 1 x PCI Express x16 slot, integrated in the CPU:, AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode |
| PCI Express x4 | Chipset:, – 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 |
| Serial ATA (SATA) | 4 x SATA 6Gb/s |
| M.2 | 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:, AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs |
| SATA RAID | 0/1/5/10 |
| Audio Chipset | Realtek ALC1220 |
| Audio Channels | 7.1 Channels |
| Max LAN Speed | 5Gbps |
| Wireless LAN | Wi-Fi 802.11 be |
| Bluetooth | BLUETOOTH 5.3 |
| Back I/O Ports | 1 x Q-Flash Plus button, 1 x Clear CMOS button |
| Onboard USB | 1 x USB Type-C header, with USB 3.2 Gen 2×2 support, 2 x USB 3.2 Gen 1 headers |
| Other Connectors | 1 x CPU fan header, 1 x CPU fan/water cooling pump header |
| Dimensions (W x L) | 12.0″ x 9.6″ |
| Power Pin | 1 x 24-pin ATX main power connector, 2 x 8-pin ATX 12V power connectors |
| BIOS Feature | 1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS |
| Software | Norton Internet Security, LAN bandwidth management software |
| Features | Support for GIGABYTE Control Center, Support for Q-Flash |
| Form Factor | ATX |
| Memory Type | DDR5 |
Reviews
There are no reviews yet.
