ASUS ROG STRIX Z690-A GAMING WIFI LGA 1700 ATX motherboard with PCIe® 5.0, 16+1 DrMos, DDR5, Two-Way AI Noise Cancelation, AI Overclocking, AI Cooling, AI Networking, WiFi 6E, Intel 2.5 Gb Ethernet, four M.2 slots with heatsinks PCIe 4.0 NVMe® SSD support, M.2 backplate, USB 3.2 Gen 2×2 Type-C®, SATA and AURA Sync RGB lighting

Name: ASUS ROG STRIX Z690-A GAMING WIFI LGA 1700 ATX motherboard with PCIe® 5.0, 16+1 DrMos, DDR5, Two-Way AI Noise Cancelation, AI Overclocking, AI Cooling, AI Networking, WiFi 6E, Intel 2.5 Gb Ethernet, four M.2 slots with heatsinks PCIe 4.0 NVMe® SSD support, M.2 backplate, USB 3.2 Gen 2x2 Type-C®, SATA and AURA Sync RGB lighting
Brand: Asus
SKU: MC-MBD-ASU-0066
Price: 110000 PKR
Availability: InStock

SKU: MC-MBD-ASU-0066 Category: Intel Motherboards Brand: Asus

The ASUS ROG STRIX Z690-A GAMING WIFI is an ATX motherboard for Intel 12th Gen CPUs, featuring PCIe 5.0, 16+1 DrMOS, and DDR5 support. It includes WiFi 6E, Intel 2.5 Gb Ethernet, four M.2 slots with heatsinks, and AI-powered optimization for overclocking, cooling, and networking. With AURA Sync RGB and comprehensive connectivity, it’s built for high-performance gaming builds.

Shipping & Delivery

Pick up from the Megacomputer Store

To pick up today

Free

Express delivery

Applicable to selected areas in Karachi only

1-2 Days

TCS Courier delivery

Our courier partner will deliver to your specified address

Delays may occur due to situations out of our control

3-4 Days

₨ 110,000

Compare

Add to wishlist

Description

The ASUS ROG STRIX Z690-A GAMING WIFI is a premium ATX motherboard built for Intel’s 12th Gen Core processors on the LGA 1700 socket. It features PCIe 5.0 support, 16+1 DrMOS power stages, and DDR5 memory compatibility, delivering exceptional performance for gaming and content creation. With AI Overclocking, AI Cooling, and AI Networking, this board intelligently optimizes system performance and connectivity.

Equipped with WiFi 6E and Intel 2.5 Gb Ethernet, you get fast, stable networking. Four M.2 slots with heatsinks and a backplate support PCIe 4.0 NVMe SSDs, while USB 3.2 Gen 2×2 Type-C ensures high-speed data transfer. AURA Sync RGB lighting lets you customize the look, and the board includes comprehensive cooling options and Q-Design features for easy building.

Intel LGA 1700 socket with dual mounting holes for LGA1700 and LGA1200 coolers
16+1 DrMOS power stages with ProCool II power connectors
DDR5 memory support up to 5333 MHz (OC) with 4 slots, max 128GB
PCIe 5.0 x16 slot, PCIe 4.0 M.2 slots (4 total) with heatsinks and backplate
WiFi 6E (802.11ax) and Bluetooth 5.2, Intel 2.5 Gb Ethernet
AI Overclocking, AI Cooling, AI Networking, Two-Way AI Noise Cancelation

Specification

Overview

Brand	ASUS
Series	ROG
Model	STRIX Z690-A GAMING WIFI D4
Part Number	90MB18K0-M0AAY0
CPU Socket Type	LGA 1700, * Designed with dual mounting holes compatible with both Intel LGA1700 and LGA1200 cooling brackets.
CPU Type	Supports 12th Gen Intel Core Processors, Supports Intel Pentium Gold / Celeron Processors, * Refer to www.asus.com for CPU support list.
Supported CPU Technologies	Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset	Intel Z690
Onboard Video Chipset	Supported only by CPU with integrated graphic
Number of Memory Slots	4x288pin (DDR4)
Memory Standard	DDR4 5333(OC) / 5000(OC) / 4800(OC) / 4700(OC) / 4600(OC) / 4500(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3300(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133, *Actual Memory frequency support depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Maximum Memory Supported	128GB
Channel Supported	Dual Channel
PCI Express 5.0 x16	1 x PCI Express 5.0 x16, * Actual support may vary by CPU., * Please check PCIe bifurcation table in support site.
PCI Express 3.0 x16	1 x PCI Express 3.0 x16, * Supports x4 mode.
PCI Express x1	1 x PCIe 3.0 x1
SATA 6Gb/s	6 x SATA 6Gb/s
M.2	Intel 12th Gen Processors:, M.2_1 slot (Key M), type 2242/2260/2280/22110, – Intel 12th Gen processors support PCIe 4.0 x4 mode., Intel Z690 Chipset:, M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4), M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)*, Intel Rapid Storage Technology supports NVMe RAID 0/1/5, SATA RAID 0/1/5/10., ** When M.2_4 is operating in SATA mode, SATA6G_2 will be disabled.
Intel Optane Ready	Yes
Audio Chipset	Realtek ALC4080
Audio Channels	7.1 Channels
LAN Chipset	Intel 2.5Gb Ethernet
Max LAN Speed	10/100/1000/2500Mbps
Wireless LAN	Wi-Fi 6, 802.11a/b/g/n/ac/ax
Bluetooth	Bluetooth 5.2
Back I/O Ports	1 x USB 3.2 Gen 2×2 port (1 x USB Type-C), 3 x USB 3.2 Gen 2 ports (2 x Type-A, 1 x USB Type-C), 4 x USB 3.2 Gen 1 ports (4 x Type-A), 2 x USB 2.0 ports (2 x Type-A), 1 x DisplayPort, 1 x HDMI port, 1 x Wi-Fi Module, 1 x Intel 2.5Gb Ethernet port, 5 x Audio jacks, 1 x BIOS FlashBack button, 1 x Clear CMOS button
Onboard USB	1 x USB 3.2 Gen 2×2 connector (support USB Type-C), 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports, 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Other Connectors	Fan and Cooling related, 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 5 x 4-pin Chassis Fan headers, Miscellaneous, 3 x Addressable Gen 2 headers, 1 x AURA RGB header, 1 x Clear CMOS header, 1 x CPU Over Voltage jumper, 1 x 12-1 pin Front Panel Audio header (AAFP), 1 x S/PDIF Out header, 1 x SPI TPM header (14-1pin), 1 x 20-3 pin System Panel header with Chassis intrude function, 1 x Thermal Sensor header, 1 x Thunderbolt header
Form Factor	ATX
LED Lighting	RGB
Dimensions (W x L)	12.0″ x 9.6″
Power Pin	1 x 24-pin Main Power connector, 2 x 8-pin +12V Power connectors
Windows 11	Ready
Features	Special Feature:, Extreme Engine Digi+, -5K Black Metallic Capacitors, ASUS Q-Design, – M.2 Q-Latch, – PCIe Slot Q-Release, – Q-DIMM, – Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]), – Q-Slot, ASUS Thermal Solution, – M.2 heatsink backplate, – M.2 heatsink, – VRM heatsink design, ASUS EZ DIY, – BIOS FlashBack button, – BIOS FlashBack LED, – Clear CMOS button, – CPU Socket lever protector, – ProCool II, – Pre-mounted I/O shield, – SafeSlot, – SafeDIMM, AURA Sync, – AURA RGB header, – Addressable Gen 2 headers, ASUS HYDRANODE, – 1 x 12-1 pin Front Panel Audio header (AAFP), – 1 x Chassis fan support* (CHA_FAN1P), * Visit ASUS Website for the latest compatibility list., Software Features:, ROG Exclusive Software, – GameFirst VI, – ROG CPU-Z, – Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion, – Sonic Radar III, – DTS Sound Unbound, – Anti-virus software, ASUS Exclusive Software, Armoury Crate, – AIDA64 Extreme (60 days free trial), – AURA Creator, – AURA Sync, – Fan Xpert 4, – Two-Way AI Noise Cancelation, AI Suite 3, – 5-Way Optimization with AI Overclocking, TPU, EPU, DIGI+ VRM, Fan Xpert 4, Turbo app, MyAsus, WinRAR, UEFI BIOS, AI Overclocking Guide, ASUS EZ DIY, – ASUS CrashFree BIOS 3, – ASUS EZ Flash 3, – ASUS UEFI BIOS EZ Mode, FlexKey, MemTest86, BIOS:, 256 Mb Flash ROM, UEFI AMI BIOS, Manageability:, WOL by PME, PXE, Operating System:, Windows 11 64-bit, Windows 10 64-bit
Package Contents	Accessories:, Cables, 4 x SATA 6Gb/s cables, Miscellaneous, 1 x ASUS Wi-Fi moving antennas, 1 x Cable ties pack, 1 x M.2 Rubber Package, 1 x M.2 Q-Latch package, 1 x ROG key chain, 1 x ROG Strix stickers, 1 x ROG Strix thank you card, Installation Media, 1 x Support DVD, Documentation, 1 x User guide
Form Factor	ATX
Memory Type	DDR5
