MSI PRO B650M-P AM5 Micro-ATX Motherboard
The MSI PRO B650M-P is a Micro-ATX motherboard for AMD AM5 processors, featuring the B650 chipset. It supports DDR5 memory up to 6000 MT/s, dual M.2 PCIe 4.0 slots, and a Realtek 2.5Gbps LAN. With versatile connectivity and a 2-year warranty, it’s a solid foundation for a modern PC build, available nationwide with cash on delivery.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 38,799
Description
The MSI PRO B650M-P is a Micro-ATX motherboard built for AMD Ryzen 7000 series processors on the AM5 socket. It supports DDR5 memory up to 6000 MT/s and offers dual-channel architecture with a maximum capacity of 192 GB. Storage options include two M.2 PCIe 4.0 x4 slots and four SATA III ports, with RAID support for both.
Connectivity features a Realtek 8125BG 2.5Gbps LAN, multiple USB headers (including USB-C), and display outputs via VGA, HDMI 1.4, and DisplayPort 1.4. The board includes four RGB headers, a pump header for liquid cooling, and robust power delivery with an 8-pin CPU power connector. Backed by a 2-year warranty, this motherboard is ideal for reliable daily computing.
- AMD B650 chipset with AM5 socket for Ryzen 7000 series CPUs
- 4x DDR5 slots supporting up to 192 GB (dual channel, 4800-6000 MT/s)
- 2x M.2 PCIe 4.0 x4 slots and 4x SATA III with RAID 0/1/10
- Realtek 8125BG 2.5Gbps LAN and multiple USB ports including USB-C
- Micro-ATX form factor with 4x RGB headers and comprehensive cooling options
Specification
Overview
| Warranty | 2 Years |
|---|---|
| Chipset | AMD B650 |
| CPU Socket | AM5 |
| Memory Slots | 4x 288-Pin |
| Memory Support | DDR5 4800, 5000, 5200, 5400, 5600, 5800, 6000 MT/s |
| Storage Slots | 2x M.2 (M Key) 2260, 2280 (PCIe 4.0 x4) |
| Expansion Slots | 1x PCIe 4.0 x16, 2x PCIe 3.0 x1 |
| Wi-Fi | No |
| Form Factor | Micro-ATX |
| USB | 1x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-A Port), 2x USB 2.0 Header (Supports 4 USB-A Port), 1x USB 3.1/3.2 Gen 2 Header (Supports 1 USB-C Port) |
| Thunderbolt | No |
| Display | 1x VGA Output, 1x HDMI 1.4 Output, 1x DisplayPort 1.4 Output |
| Audio | 3x 1/8″ / 3.5 mm |
| Ethernet / Controller | 1x Realtek 8125BG 2.5Gigabit |
| PS/2 | 1x PS/2 |
| Maximum Capacity | 192 GB |
| Channel Architecture | Dual Channel |
| ECC Support | Non-ECC Unbuffered |
| SATA | 4x SATA III |
| Optane Memory Support | No |
| RAID Support | RAID 0, 1, 10 (SATA), RAID 0, 1 (M.2) |
| Air Cooling | 1x 4-Pin CPU, 3x 4-Pin System |
| Liquid Cooling | 1x 4-Pin Pump |
| Power Connectors | 1x 24-Pin Mainboard, 1x 8-Pin ATX |
| Security | Chassis Intrusion, TPM Module, TPM Header |
| LED Header | 4x RGB |
| Diagnostics | Clear CMOS |
| Audio Codec | Realtek ALC897 (7.1-Channel) |
| DAC | No |
| Bluetooth | No |
| OS Compatibility | Windows 10 to 11 (64-Bit Only) |
| Dimensions | 9.6 x 9.6″ / 243.8 x 243.8 mm |
| Package Weight | 2.29 lb |
| Box Dimensions (LxWxH) | 12.4 x 11.9 x 2.1″ |
| Form Factor | Micro-ATX |
