ASUS PRIME A520M-K-CSM AM4 AMD A520 SATA 6Gb/s Micro ATX AMD Motherboard
The ASUS PRIME A520M-K-CSM is a Micro ATX motherboard for AMD Ryzen processors, featuring the A520 chipset. It supports up to 64GB DDR4 memory with overclocking, 1 M.2 slot, 4 SATA ports, Realtek 1Gb LAN, and 7.1-channel audio. With ASUS 5X Protection III, it offers reliable performance for home and office builds.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 22,699
Description
The ASUS PRIME A520M-K-CSM is a reliable Micro ATX motherboard built for AMD Ryzen processors, supporting the latest 5000 Series and 3000 Series CPUs. With the AMD A520 chipset, it delivers solid performance for everyday computing and light gaming. The board features 2 DIMM slots supporting up to 64GB of DDR4 memory with overclocking capabilities up to 4866 MHz, ensuring smooth multitasking.
Connectivity includes 1 x M.2 slot and 4 x SATA 6Gb/s ports for fast storage, plus Realtek 1Gb Ethernet and 7.1-channel audio for immersive sound. ASUS 5X Protection III safeguards the motherboard against power surges, static discharge, and other electrical threats, enhancing durability.
- AMD AM4 socket compatible with Ryzen 5000/4000/3000 Series desktop processors
- DDR4 memory support up to 64GB with overclocking up to 4866 MHz
- 1 x M.2 slot and 4 x SATA 6Gb/s ports for flexible storage options
- Realtek RTL8111H 1Gb Ethernet and ALC887/897 7.1-channel audio
- ASUS 5X Protection III for enhanced reliability and longevity
- Micro ATX form factor fits compact builds
Specification
Overview
| Warranty | 2 Years |
|---|---|
| Model | PRIME A520M-K/CSM |
| CPU | AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors * |
| Chipset | AMD A520 |
| Memory | 2 x DIMM, Max. 64GB, DDR4 4866(O.C)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory * |
| Graphic | 1 x D-Sub |
| Expansion Slots | AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors |
| Storage | Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports |
| LAN | Realtek RTL8111H 1Gb Ethernet |
| Audio | Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC * |
| Software Features | ASUS Exclusive Software |
| ASUS Special Features | ASUS 5X PROTECTION III |
| Back I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) |
| Internal I/O Ports | 1 x CPU Fan connector(s) |
| Accessories | User´s manual |
| Form Factor | Micro-ATX |
