MSI PRO B760M-E DDR4 Micro-ATX LGA 1700 Motherboard
The MSI PRO B760M-E DDR4 is a Micro-ATX motherboard supporting Intel Core 14th, 13th, and 12th Gen processors on the LGA 1700 socket. It features dual-channel DDR4 memory up to 64GB, PCIe 4.0 x16 slot, M.2 Gen4 storage, and Realtek Gigabit LAN. With HDMI and VGA outputs, this board delivers reliable performance for everyday computing and is backed by a 2-year warranty.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 32,825
Description
The MSI PRO B760M-E DDR4 is a Micro-ATX motherboard built on the Intel B760 chipset, supporting Intel Core 14th, 13th, and 12th Gen processors in the LGA 1700 socket. It offers a solid foundation for business or home office PCs, with dual-channel DDR4 memory support up to 64GB and overclocking capabilities up to 4800+ MHz.
Connectivity includes HDMI 1.4 and VGA outputs for integrated graphics, a PCIe 4.0 x16 slot for a graphics card, one M.2 slot with PCIe 4.0 x4 support, and four SATA 6G ports. The board also features Realtek Gigabit LAN, 7.1-channel HD audio, and multiple USB 3.2 Gen1 and USB 2.0 ports. With EZ Debug LEDs for troubleshooting and a compact mATX form factor, this motherboard is a reliable choice for everyday computing.
- Intel B760 chipset with LGA 1700 socket for 14th/13th/12th Gen Core processors
- 2x DDR4 DIMMs, up to 64GB, with overclocking support up to 4800+ MHz
- 1x PCIe 4.0 x16 slot, 1x PCIe 3.0 x1 slot
- 1x M.2 slot (PCIe 4.0 x4 / SATA), 4x SATA 6G with RAID 0/1/5/10
- Realtek RTL8111H Gigabit LAN, Realtek ALC897 7.1-channel audio
- HDMI 1.4 (4K@30Hz) and VGA outputs; 4x USB 3.2 Gen1, 8x USB 2.0
Specification
Overview
| Brand | MSI |
|---|---|
| Model | PRO B760M-E |
| Form Factor | Micro-ATX |
| Socket | LGA 1700 |
| Memory Type | DDR4 |
| Max Memory Speed | 4800+ MHz |
| Supported CPU Generations | Intel 14th/13th/12th Gen |
| Warranty | 2 Years |
| CHIPSET | INTEL B760 |
| CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors, LGA 1700 |
| MEMORY | 2x DDR4, Maximum Memory Capacity 64GB, Memory Support 4800/ 4600/ 4400/ 4266/ 4200/ 4000/ 3800/ 3733/ 3600/ 3466/ 3400/ 3333/ 3200/ 2933/ 2666/ 2400/ 2133 |
| ONBOARD GRAPHICS | 1x HDMI™, Support HDMI™ 1.4 with HDR, maximum resolution of 4K 30Hz* |
| SLOT | 1x PCI-E x16 slot, 1x PCI-E x1 slot |
| STORAGE | 1x M.2, M.2_1 Source supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| USB | 4x USB 2.0, 4x USB 2.0 |
| LAN | Realtek, ® |
| AUDIO | Realtek, ® |
| INTERNAL IO | 1x Power Connector, 1x Power Connector |
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS | |
| OPERATING SYSTEM | Support for Windows, ® |
| PCB INFO | mATX, 200mmx236.16mm |
| Form Factor | Micro-ATX |
| Memory Type | DDR4 |
