Cooler Master Elite Gold 1000W 80+ Gold Fully Modular ATX 3.1 Power Supply – Black
The Cooler Master Elite Gold 1000W is a fully modular ATX 3.1 power supply with 80 PLUS Gold efficiency, delivering reliable 1000W power for high-end gaming or workstation builds. It features all-Japanese capacitors, a native 12+4 pin connector, and comprehensive protections, backed by a 2-year warranty. Available with nationwide delivery and cash-on-delivery across Pakistan.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 41,410
Description
The Cooler Master Elite Gold 1000W is a fully modular ATX 3.1 power supply built for high-performance systems. With 80 PLUS Gold certification, it delivers ≥90% efficiency at typical loads, reducing energy waste and heat. All-Japanese capacitors ensure long-term reliability, backed by a 2-year warranty.
Designed for modern GPUs, it includes a native 12+4 pin connector (600mm) and three PCI-e 6+2 pin connectors. The 120mm rifle bearing fan provides quiet cooling, while comprehensive protections (UVP/OVP/OPP/OTP/SCP) safeguard your components. Compact dimensions (140x150x86mm) make it suitable for most ATX cases.
- 1000W fully modular design for clean cable management
- 80 PLUS Gold efficiency (≥90% @ Typical Load)
- ATX 3.1 compliant with native 12+4 pin connector
- All-Japanese capacitors for enhanced durability
- 120mm rifle bearing fan with quiet operation
- 6 protection features: UVP/OVP/OPP/OTP/SCP
Specification
Overview
| Warranty | 2 Years |
|---|---|
| Product Name | Elite Gold 1000 (All-Japanese Capacitors) |
| Model | MPX-A005-AFAG |
| Series | Elite Series |
| Form Factor | ATX |
| ATX Version | ATX 12V Ver. 3.1 |
| Wattage | 1000W |
| Modular | Fully Modular |
| PFC | Active PFC |
| Input Voltage | 100–240V |
| Input Current | 6 ~ 12A |
| Input Frequency | 50–60Hz |
| Dimensions (L x W x H) | 140 x 150 x 86 mm |
| Fan Size | 120mm |
| Fan Bearing | Rifle Bearing |
| Efficiency | ≥90% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Gold |
| 80 Plus Efficiency | Gold |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0–40°C |
| Power Good Signal | 100 – 150 ms |
| Hold Up Time | ≥16 ms @ 80% Load |
| MTBF | >100,000 hours @ 25°C ambient |
| Protections | UVP / OVP / OPP / OTP / SCP |
| Regulatory Certifications | cTUVus, CB, CE, FCC, BSMI, EAC, RCM, UKCA, RoHS2.0, REACH |
| ATX 24-Pin Connector | 1 × (600mm) |
| SATA Connectors | 3 × (500 + 100 + 100 mm) |
| Peripheral 4-Pin Connectors | 1 × (500 + 100 + 100 mm) |
| eps-4-4-pin-connectors | 2 × (700mm) |
| pci-e-6-2-pin-connectors | 3 × (550 + 120 mm) |
| 12-4-pin-connector | 1 × (600mm) |
| EPS 4+4 Pin Connectors | 2 × |
| PCI-e 6+2 Pin Connectors | 3 × |
| 12+4 Pin Connector | 1 × |
