COLORFUL BATTLE-AX B450M-K M.2 V14 AMD AM4 DDR4 mATX Motherboard
The COLORFUL BATTLE-AX B450M-K M.2 V14 is an AMD AM4 mATX motherboard featuring the B450 chipset, supporting Ryzen processors and dual-channel DDR4 memory up to 4000MHz (OC). With an M.2 slot, four SATA ports, HDMI 2.0, and USB 3.2 Gen 1 connectivity, it’s a solid foundation for a reliable PC build. Available with nationwide delivery and cash-on-delivery across Pakistan.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 20,500
Description
The COLORFUL BATTLE-AX B450M-K M.2 V14 is a reliable mATX motherboard built on the AMD B450 chipset, supporting a wide range of AMD Ryzen processors for the AM4 socket. It offers dual-channel DDR4 memory with overclocking support up to 4000MHz, and includes a full suite of connectivity options for modern builds.
This motherboard features one M.2 slot for high-speed SSDs (PCIe 3.0 x4/SATA) and four SATA 6Gb/s ports, ensuring flexible storage configurations. The rear I/O includes USB 3.2 Gen 1 Type-A ports, HDMI 2.0 (4K@60Hz), VGA, and a Gigabit Ethernet port, while onboard headers provide additional USB and fan controls.
- AMD B450 chipset with AM4 socket support for Ryzen processors
- 2 DDR4 slots, up to 64GB, supporting OC speeds up to 4000MHz
- 1 M.2 slot (PCIe 3.0 x4/SATA) and 4 SATA 6Gb/s ports
- Rear I/O: 4x USB 3.2 Gen 1, 2x USB 2.0, HDMI 2.0, VGA, PS/2, Gigabit LAN, 3 audio jacks
- Realtek ALC897 audio codec with up to 5.1 channels
- mATX form factor (230mm x 197mm), 1-year warranty
Specification
Overview
| Warranty | 1 Year |
|---|---|
| Model | BATTLE-AX B450M-K M.2 V14 |
| Product Series | BATTLE-AX series |
| Chipset | AMD B450 |
| Processor | Supports AMD Ryzen series processors that fit the AMD AM4 slot of the motherboard, (* Please visit www.colorful.cn for the latest memory compatibility list) |
| Memory | 2 DDR4 memory sockets are provided, which can support up to 64GB of memory (a single socket can support up to 32 GB of memory), – Support DDR4-4000(OC)/3733(OC)/3600(OC)/3466(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2666/2400/2133MHz memory, – Support Extreme Memory Profile (XMP) memory technology, – Supports dual channel memory technology, (* Please visit www.colorful.cn for the latest memory compatibility list) |
| SATA Ports | 1 M.2 slot and 4 SATA 6Gb/s hard disk interfaces, – M.2_1 slot: supports 2242/2280 M.2 SSD (PCIe 3.0 x4/SATA, CPU channel) |
| Board I/O | Rear I/O :, -2×USB 2.0 interfaces, -4×USB 3.2 Gen 1 Type-A interfaces, -1×HDMI 2.0 interface, Supports up to 4K 60Hz resolution, -1×VGA interface, -1×PS/2 interface, -1×Gigabit network interface, -3×Audio interfaces (audio input/audio output/microphone), On board:, -1×CPU fan pin, -1×System fan pin, -1×USB 2.0 pin expandable 2 USB 2.0 Type-A interfaces, -1×USB 3.2 Gen 1 pin expandable 2 USB 3.2 Gen 1 Type-A interfaces, -1×Front audio pin, -1×Front panel pin, -1×Speaker pin, -1×Digital audio pin, -1×Clear CMOS jumper, -1×BIOS burner pin, -1×Debug light pin, -1×USB live control jumper |
| Expansion Slots | 1×PCIe 3.0 x16 slot, 1×PCIe 2.0 x1 slot |
| BIOS | 128M UEFI, support multiple languages |
| Power Management | Support S3/S4 wake-up, network S5 wake-up, support USB wake-up, support timing boot, call boot |
| Hardware Monitor | CPU fan speed is controllable, system fan speed is controllable, CPU temperature monitoring, system temperature monitoring, and each group of voltage monitoring |
| LAN | RTL8111H Gigabit Network Card |
| Audio | Realtek ALC897 high fidelity decoding chip, Support up to 5.1 channels |
| Configuration | M-ATX, 230mm x 197mm |
| Form Factor | Micro-ATX |
| Memory Type | DDR4 |
