DeepCool PN1200M Series 1200W ATX 3.1 Power Supply
The DeepCool PN1200M Series 1200W Power Supply delivers reliable, high-efficiency power with ATX 3.1 support and 80Plus Gold certification. Its 135mm FDB fan ensures quiet cooling, while Japanese capacitors and multiple protections provide long-lasting stability. Ideal for demanding builds, it offers nationwide delivery across Pakistan with cash-on-delivery options.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 52,500
Description
The DeepCool PN1200M Series 1200W Power Supply is built on the ATX12V V3.1 standard, offering robust and reliable power for high-end gaming or workstation builds. With an 80Plus Gold efficiency certification, it delivers up to 90% efficiency under typical loads, reducing energy waste and heat output.
Featuring a 135mm FDB fan and a half-bridge SRC LLC + DC to DC topology, this PSU ensures stable power delivery with minimal noise. Japanese bulk capacitors and comprehensive protections (OPP, OVP, SCP, OTP, OCP, UVP, SIP, NLO) guarantee long-term durability and safety. The compact 150×150×86mm dimensions make it compatible with most mid-tower cases.
- 1200W continuous output with ATX 3.1 compliance
- 80Plus Gold certified for high efficiency
- 135mm FDB fan for quiet operation
- Japanese bulk capacitors for reliability
- Full protection suite: OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
- MTBF of 100,000 hours
Specification
Overview
| Type | ATX12V V3.1 |
|---|---|
| Product Dimensions | 150×150×86mm (W x L x H) |
| Efficiency certification | 80Plus Gold |
| Fan Size | 135mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Japanese Bulk Capacitor |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms(80% Load) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 – 40℃ |
| Regulatory | CE/FCC/CCC/TUV-RH/cTUVus/RCM/EAC/BIS |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
