Gigabyte B760M D2H DDR4 Ultra Durable 13th and 12th Gen Intel mATX Motherboard

Name: Gigabyte B760M D2H DDR4 Ultra Durable 13th and 12th Gen Intel mATX Motherboard
Brand: Gigabyte
SKU: MC-MBD-GIG-0129
Price: 35500 PKR
Availability: InStock

SKU: MC-MBD-GIG-0129 Category: Intel Motherboards Brand: Gigabyte

The Gigabyte B760M D2H DDR4 Ultra Durable motherboard supports 13th and 12th Gen Intel processors with LGA1700 socket and Intel B760 chipset. It features dual M.2 PCIe 4.0 slots, 2.5GbE LAN, DDR4 memory up to 5333MHz (OC), and HDMI/DisplayPort outputs. Built with Ultra Durable components and Q-Flash Plus, it’s ideal for reliable performance. Available with nationwide delivery and cash-on-delivery in Pakistan.

Shipping & Delivery

Pick up from the Megacomputer Store

To pick up today

Free

Express delivery

Applicable to selected areas in Karachi only

1-2 Days

TCS Courier delivery

Our courier partner will deliver to your specified address

Delays may occur due to situations out of our control

3-4 Days

₨ 35,500

Compare

Add to wishlist

Description

The Gigabyte B760M D2H DDR4 Ultra Durable motherboard is built for 13th and 12th Gen Intel processors (LGA1700 socket) with the Intel B760 Express chipset. Its Micro ATX form factor fits compact builds while offering robust connectivity including dual M.2 PCIe 4.0 slots, four SATA 6Gb/s ports, and 2.5GbE LAN. DDR4 memory support up to 5333MHz (OC) and dual-channel architecture ensure smooth multitasking and gaming performance.

Designed with Gigabyte’s Ultra Durable technology, this motherboard features solid capacitors, anti-sulfur resistors, and advanced thermal design for long-term reliability. It includes HDMI, DisplayPort, D-Sub outputs for integrated graphics, plus USB 3.2 Gen 1 and USB 2.0 ports. Q-Flash Plus allows BIOS updates without a CPU. Available with nationwide delivery across Pakistan including Karachi, Lahore, and Islamabad, with cash-on-delivery option.

Supports 13th/12th Gen Intel Core, Pentium Gold, and Celeron processors (LGA1700)
Intel B760 chipset with dual M.2 PCIe 4.0 x4 slots and 4x SATA 6Gb/s
DDR4 dual-channel memory, up to 64GB, overclockable to 5333MHz
Integrated graphics outputs: HDMI 4K@60Hz, DisplayPort, D-Sub
Realtek 2.5GbE LAN for high-speed networking
Ultra Durable components, Q-Flash Plus, and RGB LED headers

Specification

Overview

Warranty	1 Year
Supported CPU	LGA1700 socket: Support for the 13th and 12th Generation Intel Core,, Pentium Gold and Celeron Processors, L3 cache varies with the CPU
Chipset	Intel B760 Express Chipset
BIOS	1 x 128 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Audio	1 x front panel audio header, 3 x audio jacks
PCI	1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16), 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
M.2 Socket	1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU), 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB), 4 x SATA 6Gb/s connectors
Type	DDR4
Slots	2
Supported Memory	Support for DDR4 5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s memory modules, Dual channel memory architecture, Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules
Maximum Memory	64GB
Graphics	Integrated Graphics Processor-Intel HD Graphics support:, 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz, 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz
HDMI	1x HDMI
Display Port (s)	1x DisplayPort
USB (s)	6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header), 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header), 4 x USB 2.0/1.1 ports available through the internal USB headers
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps), 1 x RJ-45 port
Supported Storage	1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU), 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB), 4 x SATA 6Gb/s connectors
RAID	Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Internal I/O Ports	1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 2 x system fan headers, 2 x M.2 Socket 3 connectors, 4 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x S/PDIF Out header, 1 x USB 3.2 Gen 1 header, 3 x USB 2.0/1.1 headers, 1 x serial port header, 1 x Q-Flash Plus button, 1 x reset button, 1 x reset jumper, 1 x Clear CMOS jumper
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Special Features	2 x addressable LED strip headers, 2 x RGB LED strip headers, iTE I/O Controller Chip, Support for GIGABYTE Control Center (GCC), Support for Q-Flash, Support for Q-Flash Plus
Form Factor	Micro-ATX
Memory Type	DDR4
