ASUS Prime AP201 Tempered Glass Micro ATX Gaming Case White
The ASUS Prime AP201 Tempered Glass Micro ATX Gaming Case in White is a compact chassis supporting Micro-ATX and Mini-ITX motherboards. It accommodates ATX power supplies, GPUs up to 338 mm, and CPU coolers up to 170 mm. With versatile cooling options including top 360 mm radiator support and a tempered glass side panel, this case delivers both performance and style for your build.
Shipping & Delivery
-
Pick up from the Megacomputer Store
To pick up today
Free
-
Express delivery
Applicable to selected areas in Karachi only
1-2 Days
-
TCS Courier delivery
Our courier partner will deliver to your specified address
Delays may occur due to situations out of our control
3-4 Days
₨ 21,500
Description
The ASUS Prime AP201 Tempered Glass Micro ATX Gaming Case in White offers a compact yet spacious design for building powerful Micro-ATX or Mini-ITX systems. Despite its small footprint (205 x 350 x 460 mm), it supports full-size ATX power supplies up to 180 mm, high-end graphics cards up to 338 mm, and CPU coolers up to 170 mm. The tempered glass side panel showcases your components, while the white finish provides a clean aesthetic.
Cooling is versatile with support for up to 6 fans: 3 x 120 mm or 2 x 140 mm on top, 2 x 120 mm on bottom, and 1 x 120 mm on rear (one included). Top radiator support up to 360 mm ensures liquid cooling compatibility. The case includes a USB-C 3.2 Gen 2 port and two USB-A 3.0 ports on the front I/O.
- Micro-ATX and Mini-ITX motherboard support
- ATX PSU support (up to 180 mm) with middle mounting
- GPU clearance up to 338 mm and CPU cooler height up to 170 mm
- Top radiator support up to 360 mm
- Includes 1 x 120 mm rear fan; supports up to 6 fans total
- Front I/O: 2 x USB-A 3.0, 1 x USB-C 3.2 Gen 2, audio jacks
Specification
Overview
| Warranty | No Warranty |
|---|---|
| Motherboard Support | Micro-ATX, Mini-ITX |
| External Drive Bays | None |
| Internal Drive Bays | 1 x, 2.5″, and, 3 x, 2.5/3.5″ |
| Expansion Slots | 4 x, Full Height |
| Maximum GPU Length | 13.3″ / 338 mm |
| CPU Cooler Height | 6.7″ / 170 mm |
| Supported PSU Size | ATX |
| Maximum PSU Length | 7.1″ / 180 mm |
| PSU Mounting Location | Middle |
| Fan Mounting (Rear) | 1 x, 120 mm |
| Fan Mounting (Top) | 3 x, 120 mm, or, 2 x, 140 mm |
| Fan Mounting (Bottom) | 2 x, 120 mm |
| Fans Included (Rear) | 1 x, 120 mm |
| Maximum Radiator Size (Rear) | 120 mm |
| Maximum Radiator Size (Top) | 360 mm |
| Fan Controller Included | No |
| Filter Locations | Bottom |
| I/O | 2 x, USB-A (USB 3.0 / 3.1/3.2 Gen 1), 1 x, USB-C (USB 3.1/3.2 Gen 2) |
| Media/Memory Card Slot | None |
| Audio I/O | 1 x, 3.5 mm Input, 1 x, 3.5 mm Output |
| Display Connections | None |
| Windowed Panel | No |
| Color | Black |
| Built-In Lighting | No |
| Tool-Less Design | Yes |
| Cable Management Space | 1.3″ / 32 mm |
| Dimensions (W x H x D) | 0.7 x 1.1 x 1.5′ / 205 x 350 x 460 mm |
| Weight | 12.8 lb / 5.8 kg |
